WDA-D22-M-W4 Click:


Standard resistance Independent linearity Mechanical angle Active angle Operating life
1,2,5,10K ohm ≤1%~≤0.3% 360° 90° 180°320° 20×106
Max:20KΩ, ±5% Option on request   Optional angle Resis.change≤10%



Rotary potentiometer of WDA-D22-M-W4 is used for the measurement of angle. With the help of conductive plastic resistance track and multi-fingered precious metal wipers, the product could run glidingly with low noise output.
Technical Specification
Effective electrical angle 320°
Total resistancce 1,5,20KΩ
Resistance tolerance ±20%
Independent linearty ±1%(±0.5%)
Rated power 1W/70°
Output smoothess ±0.1%
Insulation resistance DC500V 100MΩ
Withstand voltage AC500V/1min
Mechanical angle 360°
Rotational torque 20*10-4N.M
Weight 15g
Operation temp range -140
Vibration 98m/s2(10G)500Hz
Shoce 490m/s2(50G)11ms
Rotational life 20*106 cycles
